Model NV090I

20A max out

  • The core is made of iron powder core
  • Decrease the noise by using at 10kHz to 200MHz
  • It is mainly applied in AC inductor, converter,switch power supplies,EMC filter,wind power,householding appliances
  • Working at -65℃ to +125℃
Request for quote ›

Core material: Iron Power

Inductance: 10uH-470uH

DC resistance(mΩ): 4.5-350.0

PCB Hole(mm):ø0.6/ø1.2/ø1.5/ø2.0

Operating temp: -65℃ to +125℃

Available versions

470uH / 1A
150uH / 5A
47uH / 10A
10uH / 20A
