Model NV106S

30A max out

  • The core is made of sendust
  • Decrease the noise by using at 10kHz to 200MHz
  • It is mainly applied in AC inductor, converter,switch power supplies,EMC filter,wind power,householding appliances
  • Working at -40℃ to +125℃
Request for quote ›

Core material: Sendust


DC resistance(mΩ): 2.0-20.0

PCB Hole(mm): ø1.5/ø1.8/ø2.0/ø2.2/ø2.5/ø2.8

Operating temp: -40℃ to +125℃

Available versions

5.6uH / 30A
10uH / 25A
27uH / 15A
47uH / 12A
68uH / 10A
100uH / 6A
