NV130I

Inductance: 10.0uH-1.5mH

Product Information

Core material: Iron Power
Inductance: 10.0uH-1.5mH
DC resistance（mΩ）: 3.0-450.0
PCB Hole(mm): ø0.7ø01.2/ø1.5/ø2.0
Operating temp: -65℃ to +125℃
Decrease the noise by using at 100kHz to 10MHz
It is mainly applied in AC inductor,converter, switch power supplies,
EMC filter,wind power,householding appliances
